CHU3N7NP Eaton Industrial Automation Components

CHU3N7NP on Powermatic Associates
Eaton

Part#:CHU3N7NP

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

CHU3N7NP Eaton - Eaton pedestal mount unmetered, Unmetered, 30A, 20A, None, Non-ground fault, Non-ground fault, None, Top, Pedestal, Circuits: 4, NEMA 14-30R, NEMA 5-20R2GFI, None, 4, 3, 0, 125/250V, 125V, None

Product Details

  • Feed Type
    Top
  • Weight
    30 pounds
  • Length
    13.6 inches
  • Type
    Unmetered
  • Number of Circuits
    4
  • Mounting Type
    Pedestal
  • Height
    39.9 inches

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
