XTFC063DDC Eaton Industrial Automation Components

Name: XTFC063DDC
Brand: Eaton

Part#:XTFC063DDC

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

XTFC063DDC Eaton - Eaton XT IEC motor control UL 508 Type F - XT IEC FVNR Combination Motor Controller,63 A,415V 50 Hz, 480V 60 Hz,1NO-1NC auxilary contact,Frame D,55 mm,16 to 63 A,Built in heater, Magnetic trip elements,Type 2 Coordination,Frame Size D, 55 m

Product Details

Frame
55 millimeters, D
Amperage
63 amperes
Weight
5.8 pounds
Type
Type 2 Coordination
Coil Voltage
415-480 volts
Height
6.75 inches
Length
8.5 inches
Trip Type
Magnetic Trip Elements

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
