1002510 Festo Process & Media Valves
Part#:1002510
Alt. Part#:VZXF-L-M22C-M-A-G2-430-H3B1-50-4
Manufacturer:Festo
Category:Process & Media Valves
Product Lifecycle:Active
Product description
angle seat valve VZXF-L-M22C-M-A-G2-430-H3B1-50-4 Pneumatically actuated angle seat valve in red brass. Over seat version, safety position closed, G thread, nominal width 2". Design structure: Poppet valve with piston actuator, Type of actuation: pneumati
Product Details
- Design Poppet valve with piston actuator
- Type of mounting Line installation
- Flow direction Above valve seat, for gaseous media
- Reset method Mechanical spring
- Operating pressure 6 bar ... 10 bar
- Temperature of medium -10 °C ... 80 °C
- Spindle seal material NBR
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Type code VZXF
- Cable connection Threaded sleeve G2 as per DIN ISO 228
- Nominal width 43 mm
- Nominal pressure of fitting PN 16
- Symbol 00991367
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Product weight 2800 g
- Valve function 2/2, closed, monostable
- Exhaust air function Without flow control option
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Material number, fitting housing CC499K
- Drive housing material Brass
- Actuation type Pneumatic
- Medium pressure 0 bar ... 4 bar
- Type of control Externally controlled
- Medium Vapor Filtered compressed air, 200 µm filter mesh
- Flow rate Kv 28 m³/h
- Valve housing material Red brass
- CE marking (see declaration of conformity) as per EU pressure equipment directive
- Sealing principle Soft
- Mounting position Any
- Pneumatic connection Internal thread G1/8
- Max. viscosity 600 mm²/s
- Ambient temperature -10 °C ... 60 °C
- Seat seal material PTFE
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
