1002531 Festo Process & Media Valves
Part#:1002531
Alt. Part#:VZXF-L-M22C-M-A-G2-450-M1-V4V4T-80-12
Manufacturer:Festo
Category:Process & Media Valves
Product Lifecycle:Active
Product description
angle seat valve VZXF-L-M22C-M-A-G2-450-M1-V4V4T-80-12 Pneumatically actuated angle seat valve in stainless steel. Over seat version, safety position closed, G thread, nominal width 2". Design structure: Poppet valve with piston actuator, Type of actuatio
Product Details
- Sealing principle Soft
- Valve function 2/2, closed, monostable
- Nominal pressure of fitting PN 40
- Operating pressure 6 bar ... 10 bar
- Ambient temperature -10 °C ... 60 °C
- Spindle seal material PTFE
- Drive housing material High-alloy stainless steel
- Actuation type Pneumatic
- Cable connection Threaded sleeve G2 as per DIN ISO 228
- Nominal width 45 mm
- Type of control Externally controlled
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Seat seal material PTFE
- Type code VZXF
- Mounting position Any
- Medium pressure 0 bar ... 12 bar
- Medium Vapor Filtered compressed air, 200 µm filter mesh
- Flow rate Kv 43 m³/h
- Valve housing material Cast stainless steel
- CE marking (see declaration of conformity) as per EU pressure equipment directive
- Design Poppet valve with piston actuator
- Type of mounting Line installation
- Reset method Mechanical spring
- Symbol 00991367
- Max. viscosity 600 mm²/s
- Temperature of medium -40 °C ... 200 °C
- Product weight 5400 g
- Flow direction Above valve seat, for gaseous media
- Exhaust air function Without flow control option
- Pneumatic connection Internal thread G1/8
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Material number, fitting housing 1.4408
- Corrosion resistance class (CRC) 3 - High corrosion stress
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
