133028 Festo Pneumatic Fittings
Part#:133028
Alt. Part#:QSM-M5-2
Manufacturer:Festo
Category:Pneumatic Fittings
Product Lifecycle:Active
Product description
push-in fitting QSM-M5-2 male thread with external hexagon. Size: Mini, Nominal size: 1,1 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Container size: 10
Product Details
- Maritime classification See certificate
- Type of seal on screwed trunnion Sealing ring
- Operating pressure for entire temperature range -0.95 bar ... 6 bar
- Information on operating and pilot media Operation with oil lubrication possible
- Pneumatic connection 1 External thread M5
- Material of tubing seal NBR
- Size Mini
- Pack size 10
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-]
- Nominal tightening torque 1.33 Nm
- Product weight 2.2 g
- Releasing ring material POM
- Nominal width 1.1 mm
- Mounting position Any
- Temperature-dependent operating pressure -0.95 bar ... 14 bar
- Ambient temperature -10 °C ... 80 °C
- Releasing ring color Blue
- Housing material PBT
- Material of tube retaining claw High-alloy stainless steel
- Type code QSM
- Design Push-pull principle
- Tolerance for nominal tightening torque ± 20%
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Pneumatic connection 2 for pneumatic tubing outside diameter 2 mm
- Note on materials RoHS-compliant
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
