1396090 Festo Vacuum Cups
Part#:1396090
Alt. Part#:VAS-30-1/8-PUR-B
Manufacturer:Festo
Category:Vacuum Cups
Product Lifecycle:Active
Product description
suction cup VAS-30-1/8-PUR-B Sealing ring is not included in the scope of delivery. Suction cup height compensator: 1,9 mm, Nominal size: 3 mm, suction cup diameter: 30 mm, suction cup volume: 1,29 cm3, Effective suction diameter: 24,8 mm
Product Details
- Operating pressure -0.95 bar ... 0 bar
- Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-]
- Vacuum connection G1/8
- Material of screwed trunnion Brass
- Suction cup height compensation 1.9 mm
- Effective suction cup diameter 24.8 mm
- Mounting position Any
- Holding force at nominal operating pressure 34 N
- Color Blue
- Nominal width 3 mm
- Type code VAS
- Nominal operating pressure -0.7 bar
- Ambient temperature -20 °C ... 60 °C
- Note on materials RoHS-compliant
- Suction cup volume 1.29 cm³
- Suction cup shape Round, flat
- Symbol 00991485
- Type of mounting Via vacuum connection
- Shore hardness 60 +/- 5
- Suction cup diameter 30 mm
- Connection position Top
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Product weight 12 g
- Suction cup material PUR
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
