1489945 Festo Process & Media Valves

Name: 1489945
Brand: Festo

Part#:1489945

Alt. Part#:VZWP-L-M22C-G14-130-V-1P4-40

Manufacturer:Festo

Category:Process & Media Valves

Product Lifecycle:Active

Product description

solenoid valve VZWP-L-M22C-G14-130-V-1P4-40 Servo-controlled, with piston, G1/4" connection. Design structure: Pilot-actuated piston poppet valve, Type of actuation: electrical, Sealing principle: soft, Assembly position: Coil preferably on top, Mounting

Product Details

Sealing principle
Soft
Nominal pressure of fitting PN
40
Permissible voltage fluctuations
+/- 10 %
Max. viscosity
22 mm²/s
Switching time off
250 ms
Mounting position
Coil preferably on top
Type of mounting
Line installation
Flow direction
Non-reversible
Insulation class
H
Temperature of medium
-10 °C ... 80 °C
Material number of housing
CW617N
Corrosion resistance class (CRC)
1 - Low corrosion stress
Actuation type
Electrical
Electrical connection
Form A Rectangular design
Manual override
None
Coil characteristics
24 V DC: 6.8 W
Duty cycle
100%
Ambient temperature
-10 °C ... 35 °C
Standard nominal flow rate
1600 l/min
Degree of protection
IP65

Design

Pilot-controlled piston poppet valve

Nominal width

13 mm

Differential pressure

0.5 bar

Symbol

00992974

Type of control

Pilot-controlled

Flow rate Kv

1.5 m³/h

Housing material

Cast brass

Material of screws

High-alloy stainless steel

Material number of screw

1.4301

Type code

VZWP

Fitting connection

G1/4

Valve function

2/2, closed, monostable

Medium

Compressed air as per ISO 8573-1:2010 [7:4:4] Other flow media on request

Medium pressure

0.5 bar ... 40 bar

Leak rate to EN 12266-1

On switching time

100 ms

Seals material

FPM

Product weight

600 g

Note on materials

Contains paint-wetting impairment substances RoHS-compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
