156555 Festo Pneumatic Actuators
Part#:156555
Alt. Part#:ADVU-50-40-P-A
Manufacturer:Festo
Category:Pneumatic Actuators
Product Lifecycle:Active
Product description
compact cylinder ADVU-50-40-P-A For proximity sensing, piston-rod end with female thread. Stroke: 40 mm, Piston diameter: 50 mm, Cushioning: P: Flexible cushioning rings/plates at both ends, Assembly position: Any, Mode of operation: double-acting
Product Details
- Stroke 40 mm
- Mounting position Any
- Operating pressure 0.8 bar ... 10 bar
- Position sensing For proximity sensor
- Variants Piston rod at one end
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Basic weight with 0 mm stroke 560 g
- Additional moving mass per 10 mm stroke 16 g
- Type code ADVU
- Piston rod end Internal thread
- Symbol 00991217
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Ambient temperature -20 °C ... 80 °C
- Additional weight per 10 mm stroke 72 g
- Theoretical force at 6 bar, advancing 1178 N
- Cushioning Elastic cushioning rings/pads at both ends
- Design Piston Piston rod
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Impact energy in the end positions 0.64 J
- Theoretical force at 6 bar, retracting 1057 N
- Flange screws material Steel, galvanized
- Piston diameter 50 mm
- Mode of operation Double-acting
- Type of mounting Optionally: With accessories
- Material of dynamic seals NBR TPE-U(PU)
- Moving mass at 0 mm stroke 112 g
- Pneumatic connection G1/8
- Cover material Wrought aluminum alloy
- Material of cylinder barrel Wrought aluminum alloy
- Piston rod material High-alloy steel
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
156555 Related Documents
Similar products from: Festo Pneumatic Actuators
Manufacturer warranty
156555 Festo
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 156555 with other Pneumatic Actuators products
Stroke
Mounting position
Operating pressure
Position sensing
Variants
Corrosion resistance clas...
Basic weight with 0 mm st...
Additional moving mass pe...
Type code
Piston rod end
Selected product
156555
Festo
compact cylinder ADVU-50-40-P-A For proximity sensing, piston-rod end with female thread. Stroke: 40...
Stroke40 mm
Mounting positionAny
Operating pressure0.8 bar ... 10 bar
Position sensingFor proximity sensor
VariantsPiston rod at one end
Corrosion resistance class (CRC)2 - Moderate corrosion stres...
Basic weight with 0 mm stroke560 g
Additional moving mass per 10 mm stroke16 g
Type codeADVU
Piston rod endInternal thread
536248
Festo
compact cylinder ADN-20-40-I-P-A Per ISO 21287, with position sensing and internal piston rod thread...
Stroke40 mm
Mounting positionAny
Operating pressure0.6 bar ... 10 bar
Position sensingFor proximity sensor
VariantsPiston rod at one end
Corrosion resistance class (CRC)-
Basic weight with 0 mm stroke-
Additional moving mass per 10 mm stroke-
Type codeADN
Piston rod endInternal thread
536316
Festo
compact cylinder ADN-50-40-A-P-A Per ISO 21287, with position sensing and external piston rod thread...
Stroke40 mm
Mounting positionAny
Operating pressure0.6 bar ... 10 bar
Position sensingFor proximity sensor
VariantsPiston rod at one end
Corrosion resistance class (CRC)-
Basic weight with 0 mm stroke-
Additional moving mass per 10 mm stroke-
Type codeADN
Piston rod endExternal thread
