156607 Festo Pneumatic Actuators
Part#:156607
Alt. Part#:ADVU-20-50-A-P-A
Manufacturer:Festo
Category:Pneumatic Actuators
Product Lifecycle:Active
Product description
compact cylinder ADVU-20-50-A-P-A For proximity sensing, piston-rod end with male thread. Stroke: 50 mm, Piston diameter: 20 mm, Cushioning: P: Flexible cushioning rings/plates at both ends, Assembly position: Any, Mode of operation: double-acting
Product Details
- Cushioning Elastic cushioning rings/pads at both ends
- Design Piston Piston rod
- Position sensing For proximity sensor
- Theoretical force at 6 bar, retracting 141 N
- Additional moving mass per 10 mm stroke 6 g
- Material of dynamic seals NBR TPE-U(PU)
- Piston diameter 20 mm
- Variants Piston rod at one end
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Basic weight with 0 mm stroke 149 g
- Flange screws material Steel, galvanized
- Stroke 50 mm
- Mounting position Any
- Symbol 00991217
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Impact energy in the end positions 0.14 J
- Moving mass at 0 mm stroke 20 g
- Type of mounting Optionally: With accessories
- Piston rod material High-alloy stainless steel
- Mode of operation Double-acting
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Theoretical force at 6 bar, advancing 188 N
- Cover material Wrought aluminum alloy
- Type code ADVU
- Piston rod end External thread
- Operating pressure 1 bar ... 10 bar
- Ambient temperature -20 °C ... 80 °C
- Additional weight per 10 mm stroke 23 g
- Pneumatic connection M5
- Material of cylinder barrel Wrought aluminum alloy
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
