15717 Festo Compressed Air Preparation Units

15717 on Powermatic Associates
Festo

Part#:15717

Alt. Part#:LR-3,3

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

mini pressure regulator LR-3,3 Without sub-base Controller function: (* Output pressure constant, * with secondary exhaust), Mounting type: Front panel installation, Standard nominal flow rate: 150 l/min, Ambient temperature: -10 - 60 °C, Material housing

Product Details

  • Type code
    LR
  • Ambient temperature
    -10 °C ... 60 °C
  • Type of mounting
    Front panel mounting
  • Housing material
    POM
  • Pilot pressure
    8 bar
  • Design
    Diaphragm regulator with secondary exhausting
  • Note on materials
    Contains paint-wetting impairment substances
  • Standard nominal flow rate
    150 l/min
  • Operating pressure
    10 bar
  • Seals material
    NBR TPE-U(PU)
  • Controller function
    Outlet pressure constant With secondary exhausting
  • Mounting position
    Any
  • Symbol
    00991540
  • Max. pressure hysteresis
    0.3 bar

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

15717 Related Documents

15717 DataSheet.pdf
