159630 Festo Compressed Air Preparation Units

Product Details

• Size
  Mini
• Actuator lock
  Rotary knob with detent
• Design
  Filter regulator with pressure gauge
• Pressure gauge
  with pressure gauge
• Series
  D
• Condensate drain
  Manually rotating
• Operating pressure
  1 bar ... 16 bar
• Operating medium
  Compressed air as per ISO 8573-1:2010 [-:9:-] Inert gas
• Storage temperature
  -10 °C ... 60 °C
• Maritime classification
  See certificate
• Grade of filtration
  40 µm
• Bowl guard
  Metal bowl guard
• Type code
  LFR
• Mounting position
  Vertical +/- 5°
• Max. condensate volume
  22 ml
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Symbol
  00991585
• Max. pressure hysteresis
  0.2 bar
• Standard nominal flow rate
  750 l/min
• Ambient temperature
  -10 °C ... 60 °C
Pneumatic connection 1
G1/8
Material of bowl
PC
Pressure regulation range
0.5 bar ... 12 bar
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Housing material
Die-cast zinc
Air quality class at the output
Compressed air as per ISO 8573-1:2010 [7:8:4] Inert gas
Product weight
460 g
Temperature of medium
-10 °C ... 60 °C
Type of mounting
Optionally: With accessories
Note on materials
RoHS-compliant
Pneumatic connection 2
G1/8
