160518 Festo Pneumatic Fittings
Part#:160518
Alt. Part#:QSL-V0-3/8-10
Manufacturer:Festo
Category:Pneumatic Fittings
Product Lifecycle:Active
Product description
push-in L-fitting QSL-V0-3/8-10 360° orientable, male thread with external hexagon. Size: Standard, Nominal size: 8,3 mm, Material fire test: (* UL94 V-0 (housing), * UL94 V-0 (releasing ring)), Type of seal on screw-in stud: coating, Design structure: Pu
Product Details
- Material of screwed trunnion Brass, nickel-plated
- Type code QSL-V0
- Operating pressure for entire temperature range -0.95 bar ... 10 bar
- Pneumatic connection 1 R3/8
- Housing material PBT-reinforced
- Nominal width 8.3 mm
- Product weight 36 g
- Pneumatic connection 2 for pneumatic tubing outside diameter 10 mm
- Size Standard
- Type of seal on screwed trunnion Coating
- Design Push-pull principle
- Information on operating and pilot media Operation with oil lubrication possible
- Ambient temperature 0 °C ... 60 °C
- Material of tube retaining claw High-alloy stainless steel Brass
- Maritime classification See certificate
- Material fire test UL94 V-0 (housing) UL94 V-0 (releasing ring)
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
- Note on materials RoHS-compliant
- Releasing ring color Black
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
