161309 Festo Pneumatic Actuators

161309 on Powermatic Associates
Festo

Part#:161309

Alt. Part#:DZF-63-25-A-P-A

Manufacturer:Festo

Category:Pneumatic Actuators

Product Lifecycle:Active

Product description

flat cylinder DZF-63-25-A-P-A Non-rotating, for position sensing, with elastic cushioning rings in end positions. Various mounting options, with or without additional mounting components. Stroke: 25 mm, Piston diameter: (* 63 mm, * Equivalent diameter), M

Product Details

  • Stroke
    25 mm
  • Cushioning
    Elastic cushioning rings/pads at both ends
  • Piston diameter
    63 mm Equivalent diameter
  • Position sensing
    For proximity sensor
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Moving mass at 0 mm stroke
    337 g
  • Type of mounting
    Optionally: With accessories
  • Housing material
    Aluminum Smooth anodized
  • Mounting position
    Any
  • Design
    Piston Piston rod
  • Ambient temperature
    -20 °C ... 80 °C
  • Max. angle of rotation of the piston rod +/-
    0.4 deg
  • Mode of operation
    Double-acting
  • Operating pressure
    0.1 MPa ... 1 MPa
  • Theoretical force at 6 bar, advancing
    1870 N
  • Basic weight with 0 mm stroke
    1379 g
  • Type code
    DZF
  • Symbol
    00991217
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Additional weight per 10 mm stroke
    91 g
  • Seals material
    NBR TPE-U(PU)
  • Protection against torsion/guide
    Oval piston
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Max. torque for protection against rotation
    1.5 Nm
  • Pneumatic connection
    G1/4
  • Cover material
    Die-cast aluminum
  • Theoretical force at 6 bar, retracting
    1682 N
  • Additional moving mass per 10 mm stroke
    25 g
  • Piston rod material
    High-alloy steel

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

161309 Related Documents

161309 DataSheet.pdf

Similar products from: Festo Pneumatic Actuators
