162788 Festo Compressed Air Preparation Units

162788 on Powermatic Associates
Festo

Part#:162788

Alt. Part#:FRM-H-1/8-D-MINI

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

branching module FRM-H-1/8-D-MINI Pneumatic manifold with 4 connections. Assembly position: Any, Design structure: Branching module, Operating pressure: 0,15 - 16 bar, Standard nominal flow rate in main flow direction 1->2: 1100 l/min, Maritime classifica

Product Details

  • Design
    Branching module
  • Operating pressure
    0.15 bar ... 16 bar
  • Temperature of medium
    -10 °C ... 60 °C
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Air quality class at the output
    Compressed air as per ISO 8573-1:2010 [7:-:-] Inert gas
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Housing material
    Die-cast aluminum
  • Symbol
    00991511
  • Storage temperature
    -10 °C ... 60 °C
  • Pneumatic connection 2
    G1/8
  • Type code
    FRM
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Inert gas
  • Pneumatic connection 1
    G1/8
  • Pneumatic connection 4
    G1/4
  • Maritime classification
    See certificate
  • Mounting position
    Any
  • Standard nominal flow rate in main flow direction 1 -> 2
    1100 l/min
  • Ambient temperature
    -10 °C ... 60 °C
  • Pneumatic connection 3
    G1/4
  • Product weight
    325 g

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

162788 Related Documents

162788 DataSheet.pdf
