162795 Festo Compressed Air Preparation Units

162795 on Powermatic Associates
Festo

Part#:162795

Alt. Part#:FRM-H-1-D-MAXI

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

branching module FRM-H-1-D-MAXI Pneumatic manifold with 4 connections. Assembly position: Any, Design structure: Branching module, Operating pressure: 0,25 - 16 bar, Standard nominal flow rate in main flow direction 1->2: 12300 l/min, Maritime classificat

Product Details

  • Type code
    FRM
  • Symbol
    00991511
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Inert gas
  • Pneumatic connection 2
    G1
  • Mounting position
    Any
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Ambient temperature
    -10 °C ... 60 °C
  • Pneumatic connection 4
    G1/4
  • Storage temperature
    -10 °C ... 60 °C
  • Product weight
    776 g
  • Housing material
    Die-cast zinc
  • Design
    Branching module
  • Standard nominal flow rate in main flow direction 1 -> 2
    12300 l/min
  • Temperature of medium
    -10 °C ... 60 °C
  • Pneumatic connection 3
    G3/4
  • Maritime classification
    See certificate
  • Operating pressure
    0.25 bar ... 16 bar
  • Air quality class at the output
    Compressed air as per ISO 8573-1:2010 [7:-:-] Inert gas
  • Pneumatic connection 1
    G1
  • Note on materials
    Free of copper and PTFE RoHS-compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

162795 Related Documents

162795 DataSheet.pdf
