178109 Festo Pneumatic Actuators
Part#:178109
Alt. Part#:DNC-5"-10"-P-A
Manufacturer:Festo
Category:Pneumatic Actuators
Product Lifecycle:Active
Product description
profile cylinder DNC-5"-10"-P-A per ISO 15552, with profile cylinder barrel, with sensing option, non-adjustable cushioning. Stroke: 10 ", Piston diameter: 5", Piston rod thread: 1-12 UNF-2A, Based on the standard: ISO 15552 (previously also VDMA 24652, I
Product Details
- Stroke 254 mm
- Cushioning Elastic cushioning rings/pads at both ends
- Operating pressure 0.06 MPa ... 1 MPa
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Type of mounting With internal thread With accessories
- Maritime classification See certificate
- Based on norm ISO 15552 (previously also VDMA 24562, ISO 6431, NF E49 003.1, UNI 10290)
- Piston rod end External thread
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Position sensing For proximity sensor
- Mode of operation Double-acting
- Impact energy in the end positions 5 J
- Moving mass at 0 mm stroke 2809 g
- Type code DNC
- Piston diameter 5"
- Design Piston Profile barrel
- Symbol 00991217
- Piston rod thread 1-12 UNF-2A
- Mounting position Any
- Variants Piston rod at one end
- Ambient temperature -20 °C ... 80 °C
- Theoretical force at 6 bar, retracting 6881 N
- Piston rod material High-alloy steel
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Theoretical force at 6 bar, advancing 7363 N
- Pneumatic connection NPT1/2-14
- Cover material Die-cast aluminum Coated
- Additional weight per 10 mm stroke 168 g
- Basic weight with 0 mm stroke 6771 g
- Seals material TPE-U(PU)
- Additional moving mass per 10 mm stroke 63 g
- Material of cylinder barrel Wrought aluminum alloy Smooth anodized
- Note on materials RoHS-compliant
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
