186504 Festo Compressed Air Preparation Units
Part#:186504
Alt. Part#:FRC-1/4-D-7-MIDI-A
Manufacturer:Festo
Category:Compressed Air Preparation Units
Product Lifecycle:Active
Product description
service unit FRC-1/4-D-7-MIDI-A Filter/regulator/lubricator combination, maximum outlet pressure 7 bar, 40 µm filter, with metal bowl guard. With automatic condensate drain. Size: Midi, Series: D, Actuator lock: Rotary knob with lock, Assembly position:
Product Details
- Series D
- Size Midi
- Actuator lock Rotary knob with detent
- Max. condensate volume 43 ml
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Ambient temperature -10 °C ... 60 °C
- Note on materials RoHS-compliant
- Type code FRC
- Condensate drain Fully automatic
- Bowl guard Metal bowl guard
- Maritime classification See certificate
- Mounting position Vertical +/- 5°
- Grade of filtration 40 µm
- Operating pressure 2 bar ... 12 bar
- Standard nominal flow rate 1700 l/min
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Type of mounting Line installation With accessories
- Housing material Die-cast zinc
- Design Filter regulator with pressure gauge Proportional standard oil mist lubricator
- Pressure gauge with pressure gauge
- Symbol 00991509
- Max. pressure hysteresis 0.2 bar
- Air quality class at the output Compressed air as per ISO 8573-1:2010 [7:8:-] Inert gas
- Product weight 1440 g
- Pneumatic connection 2 G¼
- Pressure regulation range 0.5 bar ... 7 bar
- Operating medium Compressed air as per ISO 8573-1:2010 [7:9:-] Inert gas
- Temperature of medium -10 °C ... 60 °C
- Pneumatic connection 1 G1/4
- Material of bowl PC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
186504 Related Documents
Similar products from: Festo Compressed Air Preparation Units
Manufacturer warranty
186504 Festo
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 186504 with other Compressed Air Preparation Units products
Series
Size
Actuator lock
Max. condensate volume
Information on operating ...
Ambient temperature
Note on materials
Type code
Condensate drain
Bowl guard
Selected product
186504
Festo
service unit FRC-1/4-D-7-MIDI-A Filter/regulator/lubricator combination, maximum outlet pressure 7 b...
SeriesD
SizeMidi
Actuator lockRotary knob with detent
Max. condensate volume43 ml
Information on operating and pilot mediaOperation with oil lubricati...
Ambient temperature-10 °C ... 60 °C
Note on materialsRoHS-compliant
Type codeFRC
Condensate drainFully automatic
Bowl guardMetal bowl guard
162684
Festo
filter regulator LFR-3/8-D-MINI-A With metal bowl guard and pressure gauge. With automatic condensat...
SeriesD
SizeMini
Actuator lockRotary knob with detent
Max. condensate volume22 ml
Information on operating and pilot media-
Ambient temperature-
Note on materials-
Type codeLFR
Condensate drainFully automatic
Bowl guardMetal bowl guard
159637
Festo
filter regulator LFR-1-D-MAXI-A With metal bowl guard and pressure gauge. With automatic condensate ...
SeriesD
SizeMaxi
Actuator lockRotary knob with detent
Max. condensate volume80 ml
Information on operating and pilot media-
Ambient temperature-
Note on materials-
Type codeLFR
Condensate drainFully automatic
Bowl guardMetal bowl guard
About the manufacturer
Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to e...
About the Product Category
Also referred to as an FRL unit (Filter, Regulator, Lubricator), an air preparation unit is utilized to treat compressed air. It accomplishes this by eliminating impurities, managing pressure, and adding specific quantities of oil for lubrication.
