192461 Festo Compressed Air Preparation Units
Part#:192461
Alt. Part#:LFR-3/4-D-DI-MAXI-KA-A
Manufacturer:Festo
Category:Compressed Air Preparation Units
Product Lifecycle:Active
Product description
service unit LFR-3/4-D-DI-MAXI-KA-A consisting of filter regulator and distributor module, with mounting brackets. With automatic condensate drain. Size: Maxi, Series: D, Actuator lock: Rotary knob with lock, Assembly position: Vertical +/- 5°, Grade of f
Product Details
- Product weight 2600 g
- Type code LFR
- Design Branching module Filter regulator with pressure gauge
- Operating pressure 2 bar ... 12 bar
- Pneumatic connection 2 G3/4
- Series D
- Bowl guard Metal bowl guard
- Air quality class at the output Compressed air as per ISO 8573-1:2010 [6:8:4] Inert gas
- Operating medium Compressed air as per ISO 8573-1:2010 [-:-:-] Inert gas
- Type of mounting Optionally: With accessories
- Size Maxi
- Actuator lock Rotary knob with detent
- Max. condensate volume 43 ml
- Pressure gauge with pressure gauge
- Pressure regulation range 0.5 bar ... 12 bar
- Ambient temperature -10 °C ... 60 °C
- Housing material Die-cast zinc
- Maritime classification See certificate
- Mounting position Vertical +/- 5°
- Symbol 00991776
- Standard nominal flow rate 5800 l/min
- Pneumatic connection 1 G3/4
- Grade of filtration 40 µm
- Condensate drain Fully automatic
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Temperature of medium -10 °C ... 60 °C
- Material of bowl PC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
192461 Related Documents
Similar products from: Festo Compressed Air Preparation Units
Manufacturer warranty
192461 Festo
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 192461 with other Compressed Air Preparation Units products
Product weight
Type code
Design
Operating pressure
Pneumatic connection 2
Series
Bowl guard
Air quality class at the ...
Operating medium
Type of mounting
Selected product
192461
Festo
service unit LFR-3/4-D-DI-MAXI-KA-A consisting of filter regulator and distributor module, with moun...
Product weight2600 g
Type codeLFR
DesignBranching module Filter regu...
Operating pressure2 bar ... 12 bar
Pneumatic connection 2G3/4
SeriesD
Bowl guardMetal bowl guard
Air quality class at the outputCompressed air as per ISO 85...
Operating mediumCompressed air as per ISO 85...
Type of mountingOptionally: With accessories
159637
Festo
filter regulator LFR-1-D-MAXI-A With metal bowl guard and pressure gauge. With automatic condensate ...
Product weight-
Type codeLFR
DesignFilter regulator with pressu...
Operating pressure-
Pneumatic connection 2-
SeriesD
Bowl guardMetal bowl guard
Air quality class at the output-
Operating medium-
Type of mounting-
162684
Festo
filter regulator LFR-3/8-D-MINI-A With metal bowl guard and pressure gauge. With automatic condensat...
Product weight-
Type codeLFR
DesignFilter regulator with pressu...
Operating pressure-
Pneumatic connection 2-
SeriesD
Bowl guardMetal bowl guard
Air quality class at the output-
Operating medium-
Type of mounting-
About the manufacturer
Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to e...
About the Product Category
Also referred to as an FRL unit (Filter, Regulator, Lubricator), an air preparation unit is utilized to treat compressed air. It accomplishes this by eliminating impurities, managing pressure, and adding specific quantities of oil for lubrication.
