194852 Festo Compressed Air Preparation Units

194852 on Powermatic Associates
Festo

Part#:194852

Alt. Part#:FRCS-1/8-D-MINI

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

service unit FRCS-1/8-D-MINI Filter/pressure regulator/lubricator combination, D series, with lockable regulator head. Size: Mini, Series: D, Actuator lock: Rotary knob with integrated lock, Assembly position: Vertical +/- 5°, Condensate drain: manual rot

Product Details

  • Size
    Mini
  • Condensate drain
    Manually rotating
  • Pressure gauge
    with pressure gauge
  • Max. pressure hysteresis
    0.2 bar
  • Temperature of medium
    -10 °C ... 60 °C
  • Pneumatic connection 1
    G1/8
  • Type code
    FRCS
  • Design
    Filter regulator with pressure gauge Proportional standard oil mist lubricator
  • Max. condensate volume
    22 ml
  • Standard nominal flow rate
    700 l/min
  • Ambient temperature
    -10 °C ... 60 °C
  • Pneumatic connection 2
    G1/8
  • Actuator lock
    Rotary knob with integrated lock
  • Bowl guard
    Metal bowl guard
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [-:9:-] Inert gas
  • Note on materials
    RoHS-compliant
  • Housing material
    Die-cast zinc
  • Series
    D
  • Grade of filtration
    40 µm
  • Operating pressure
    1 bar ... 16 bar
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Product weight
    760 g
  • Mounting position
    Vertical +/- 5°
  • Symbol
    00991549
  • Pressure regulation range
    0.5 bar ... 12 bar
  • Air quality class at the output
    Compressed air as per ISO 8573-1:2010 [7:8:-] Inert gas
  • Type of mounting
    Line installation With accessories
  • Material of bowl
    PC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

194852 Related Documents

194852 DataSheet.pdf

Similar products from: Festo Compressed Air Preparation Units

162684 on Powermatic Associates

162684

Festo

filter regulator LFR-3/8-D-MINI-A With metal bowl guard and pressure gauge. With automatic condensate drain. Size: Mini, Series: D, Actuator lock: Rotary knob with lock, Assembly position: Vertical +/- 5°, Grade of filtration: 40 µm

2 in stock
162680 on Powermatic Associates

162680

Festo

lubricator LOE-3/8-D-MINI With metal bowl guard. Size: Mini, Series: D, Assembly position: Vertical +/- 5°, Design structure: proportional standard mist lubricator, Max. oil capacity: 45 cm3

1 in stock
530506 on Powermatic Associates

530506

Festo

fine filter MS6-LFM-1/2-BRV 1 µm filter, plastic bowl with plastic bowl guard, fully automatic condensate drain, flow direction from left to right. Series: MS, Size: 6, Design structure: Fibre filter, Grade of filtration: 1 µm, Condensate drain: fully aut

11 in stock
529609 on Powermatic Associates

529609

Festo

filter MS6-LF-1/2-CRV 5 µm filter, plastic bowl with plastic bowl guard, fully automatic condensate drain, flow direction from left to right. Size: 6, Series: MS, Assembly position: Vertical +/- 5°, Grade of filtration: 5 µm, Condensate drain: fully autom

15 in stock
529186 on Powermatic Associates

529186

Festo

filter regulator MS6-LFR-1/2-D7-CRV-AS Maximum output pressure 12 bar, 5 µm filter, with pressure gauge, lockable regulator head, plastic bowl with plastic bowl guard, fully automatic condensate drain, flow direction from left to right. Size: 6, Series: M

9 in stock
531229 on Powermatic Associates

531229

Festo

filter regulator MS4N-LFR-1/4-D6-CRM-AS 7 bar maximum output pressure, 5 µm filter, with pressure gauge, lockable regulator head, plastic bowl with plastic bowl guard, manual condensate drain, direction of flow: from left to right. Size: 4, Series: MS, Ac

5 in stock

Manufacturer warranty

194852 Festo

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

Compare 194852 with other Compressed Air Preparation Units products

Size

Condensate drain

Pressure gauge

Max. pressure hysteresis

Temperature of medium

Pneumatic connection 1

Type code

Design

Max. condensate volume

Standard nominal flow rat...

Selected product

194852
Backordered
194852
Festo

service unit FRCS-1/8-D-MINI Filter/pressure regulator/lubricator combination, D series, with lockab...

SizeMini

Condensate drainManually rotating

Pressure gaugewith pressure gauge

Max. pressure hysteresis0.2 bar

Temperature of medium-10 °C ... 60 °C

Pneumatic connection 1G1/8

Type codeFRCS

DesignFilter regulator with pressu...

Max. condensate volume22 ml

Standard nominal flow rate700 l/min

162684
2 in stock
162684
Festo

filter regulator LFR-3/8-D-MINI-A With metal bowl guard and pressure gauge. With automatic condensat...

SizeMini

Condensate drainFully automatic

Pressure gaugewith pressure gauge

Max. pressure hysteresis-

Temperature of medium-

Pneumatic connection 1-

Type codeLFR

DesignFilter regulator with pressu...

Max. condensate volume22 ml

Standard nominal flow rate-

159637
2 in stock
159637
Festo

filter regulator LFR-1-D-MAXI-A With metal bowl guard and pressure gauge. With automatic condensate ...

SizeMaxi

Condensate drainFully automatic

Pressure gaugewith pressure gauge

Max. pressure hysteresis-

Temperature of medium-

Pneumatic connection 1-

Type codeLFR

DesignFilter regulator with pressu...

Max. condensate volume80 ml

Standard nominal flow rate-

About the manufacturer

Festo

Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to e...

About the Product Category

Also referred to as an FRL unit (Filter, Regulator, Lubricator), an air preparation unit is utilized to treat compressed air. It accomplishes this by eliminating impurities, managing pressure, and adding specific quantities of oil for lubrication.
