30484 Festo Directional Control Valves

Product Details

• Actuation type
  Electrical
• Operating pressure
  3 bar ... 10 bar
• Sealing principle
  Soft
• Type of control
  Pilot-controlled
• Max. switching frequency
  3 Hz
• Max. negative test pulse on 1 signal
  3700 µs
• Information on operating and pilot media
  Operation with oil lubrication possible (required for further use)
• Storage temperature
  -40 °C ... 60 °C
• Pneumatic connection 3
  G1/8
• Housing material
  Die-cast aluminum
• Width
  26 mm
• Product weight
  400 g
• Pneumatic connection 2
  G1/8
• Pneumatic connection 4
  G1/8
• Valve function
  5/3, closed
• Pneumatic working port
  G1/8
• Reset method
  Mechanical spring
• Manual override
  Non-detenting
• Pilot air supply port
  Internal
• On switching time
  23 ms
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Corrosion resistance class (CRC)
1 - Low corrosion stress
Electrical connection
Via F coil, to be ordered separately
Pneumatic connection 1
G1/8
Note on materials
RoHS-compliant
Type code
MFH
Mounting position
Any
Symbol
00991033
Max. positive test pulse with 0 signal
2200 µs
Temperature of medium
-10 °C ... 60 °C
Pilot exhaust air port 82
M5
Pilot exhaust air port 84
M5
Seals material
NBR
Lap
Overlap
Standard nominal flow rate
1000 l/min
Design
Piston gate valve
Nominal width
8 mm
Flow direction
Non-reversible
Switching time off
30 ms
Changeover time
23 ms
Ambient temperature
-5 °C ... 40 °C
Type of mounting
Optionally: With through-hole
Pneumatic connection 5
G1/8
