529424 Festo Compressed Air Preparation Units

529424 on Powermatic Associates
Festo

Part#:529424

Alt. Part#:MS4-LR-1/8-D6-AS-Z

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

pressure regulator MS4-LR-1/8-D6-AS-Z 7 bar maximum output pressure, with pressure gauge, lockable regulator head, direction of flow: from right to left. Size: 4, Series: MS, Actuator lock: (* Rotary knob with lock, * with accessories, lockable), Assembly

Product Details

  • Type code
    MS4-LR
  • Controller function
    Outlet pressure constant With return flow function
  • Standard nominal flow rate
    1150 l/min
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Type of mounting
    Optionally: With accessories
  • Actuator lock
    Rotary knob with detent can be closed with accessories
  • Pressure gauge
    with pressure gauge
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Pneumatic connection 1
    G1/8
  • Seals material
    NBR
  • Size
    4
  • Mounting position
    Any
  • Symbol
    00991558
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
  • Temperature of medium
    -10 °C ... 60 °C
  • Note on materials
    RoHS-compliant
  • Compressed air filter material
    PE
  • Series
    MS
  • Operating pressure
    0.8 bar ... 14 bar
  • Max. pressure hysteresis
    0.25 bar
  • Ambient temperature
    -10 °C ... 60 °C
  • Pneumatic connection 2
    G1/8
  • Housing material
    Die-cast aluminum
  • For use in the food industry
    See supplementary material information
  • Design
    Directly controlled diaphragm regulator
  • Pressure regulation range
    0.3 bar ... 7 bar
  • Storage temperature
    -10 °C ... 60 °C
  • Product weight
    225 g
  • Material of sub-base
    Die-cast aluminum
  • Material of operator panel
    PA POM
  • Diaphragm material
    NBR

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

529424 Related Documents

529424 DataSheet.pdf
