532639 Festo Vacuum Generators

532639 on Powermatic Associates
Festo

Part#:532639

Alt. Part#:VN-10-L-T3-PQ2-VQ2-RO1-A

Manufacturer:Festo

Category:Vacuum Generators

Product Lifecycle:Active

Product description

vacuum generator VN-10-L-T3-PQ2-VQ2-RO1-A With ejector pulse. Standard, high suction rate, width 14 mm, T shape with plug connector and open silencer. Nominal size, Laval nozzle: 0,95 mm, Grid dimension: 14 mm, Design, silencer: open, Assembly position: A

Product Details

  • Seals material
    NBR
  • Material of pneumatic fitting
    Brass Nickel-plated
  • Pneumatic connection 1
    QS-6
  • Width dimension
    14 mm
  • Mounting position
    Any
  • Nominal operating pressure
    6 bar
  • Information on operating and pilot media
    Operation with oil lubrication not possible
  • Ambient temperature
    0 °C ... 60 °C
  • Type code
    VN
  • Design
    T-shape
  • Operating pressure
    1 bar ... 8 bar
  • Operating pressure for max. suction rate
    5 bar
  • Temperature of medium
    0 °C ... 60 °C
  • Product weight
    50 g
  • Material of connecting thread
    Wrought aluminum alloy, anodized
  • Material of screws
    Steel
  • Muffler construction type
    Open
  • Max. suction rate with respect to atmosphere
    40.5 l/min
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Max. tightening torque
    0.5 Nm
  • Vacuum connection
    QS-6
  • Muffler material
    PE
  • Ejector characteristics
    Standard High suction volume
  • Symbol
    00992043
  • Cleaning advice
    Soap suds
  • Type of mounting
    With through-hole With accessories
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Female nozzle material
    POM
  • Nominal width of Laval nozzle
    0.95 mm
  • Integrated function
    Ejector pulse valve, pneumatic Pneumatic muffler open
  • Air supply time at nominal operating pressure
    0.62 s
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Noise level at nominal operating pressure
    72 dB(A)
  • Pneumatic connection 3
    Pneumatic muffler open
  • Housing material
    PA-reinforced POM-reinforced
  • Material of jet nozzle
    Wrought aluminum alloy

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
