538276 Festo Proximity Sensors

Product Details

• Rated operating distance
  8 mm
• Ambient temperature
  -25 °C ... 85 °C
• Max. switching frequency AC
  25 Hz
• Operating voltage range AC
  20 V ... 265 V
• Mains frequency
  50 Hz
• Conforms to standard
  EN 60947-5-2
• Assured operating distance
  6.5 mm
• Hysteresis
  0.03 mm ... 1.9 mm
• DC operating voltage range
  20 V ... 320 V
• Reverse polarity protection
  for all electrical connections
• Mounting type
  Not flush
• Switching status indication
  LED yellow
• Symbol
  00991712
• Measuring principle
  Inductive
• Switching element function
  N/O contact
• Max. switching frequency DC
  340 Hz
• Minimum load current
  5 mA
• Material of cable sheath
  TPE-U(PUR)
• Tightening torque
  30 Nm
• Degree of protection
  IP67
Selection of sensor version
Standard
Design
Round
Note on materials
Free of copper and PTFE
Repetition accuracy
0.2 mm
Voltage drop
≤ 8 V
Idle current
≤ 1.5 mA
Cable length
2.5 m
Insulating sheath material
PVC
Housing material
Brass Nickel-plated
Type code
SIED
Certification
RCM compliance mark c UL us - Listed (OL)
CE marking (see declaration of conformity)
As per EU EMC directive As per EU low voltage directive
Reduction factors
Aluminum = 0.4 Steel St 37 = 1.0
Switching output
Non-contact, 2-wire
Max. output current
300 mA
Short-circuit protection
no
Electrical connection
2-wire Cable
Type of mounting
With lock nut
Ambient temperature with flexible cable installation
-5 °C ... 50 °C
Corrosion resistance class (CRC)
1 - Low corrosion stress
Size
M18
Product weight
110 g
Electrical output
Non-contact, 2-wire
Selection of additional sensor information
For direct and alternating voltage
