538329 Festo Proximity Sensors

Product Details

• Type code
  SIEN
• Symbol
  00991702
• Reduction factors
  Aluminum = 0.35 - 0.5 Steel St 37 = 1.0
• Switching element function
  N/O contact
• Residual ripple
  10 %
• Cable length
  2.5 m
• Size
  M12
• Housing material
  PA-reinforced
• Selection of sensor version
  Polyamide housing
• Design
  Round
• Measuring principle
  Inductive
• Ambient temperature
  -25 °C ... 70 °C
• Switching output
  PNP
• Max. switching frequency DC
  2000 Hz
• Material of cable sheath
  PVC
• Insulating sheath material
  PVC
• Mounting type
  Not flush
• Corrosion resistance class (CRC)
  4 - Particularly high corrosion stress
• Assured operating distance
  3.24 mm
• Hysteresis
  0.12 mm ... 0.6 mm
DC operating voltage range
10 V ... 30 V
Reverse polarity protection
for all electrical connections
Tightening torque
1 Nm
Switching status indication
LED yellow
Selection of additional sensor information
With standard switching distance
Certification
RCM compliance mark c UL us - Listed (OL)
CE marking (see declaration of conformity)
As per EU EMC directive
Note on materials
Free of copper and PTFE
Max. output current
200 mA
Idle current
≤ 15 mA
Electrical connection
3-wire Cable
Product weight
113 g
Ambient temperature with flexible cable installation
0 °C ... 70 °C
Conforms to standard
EN 60947-5-2
Rated operating distance
4 mm
Repetition accuracy
0.08 mm
Short-circuit protection
Pulsed
Voltage drop
≤ 1.8 V
Type of mounting
With lock nut
Degree of protection
IP65 IP67
Electrical output
PNP
