540014 Festo Actuator Accessories

Product Details

• Nominal width of Laval nozzle
  1.4 mm
• Grade of filtration
  40 µm
• KC characters
  KC EMC
• Muffler construction type
  Open
• Design
  Modular
• Measured variable
  Relative pressure
• Switching function
  Window comparator Threshold value comparator
• Display type
  4-character alphanumeric Back-lit LCD
• Switching position indication
  LCD
• Switching status indication
  Optical
• Air supply time at nominal operating pressure
  0.2 s
• Switching output
  2xNPN
• Max. output current
  100 mA
• Contamination level
  3
• Relative air humidity
  5 - 85 %
• Max. tightening torque
  0.8 Nm with internal thread 2.5 Nm with through-hole
• Electrical connection
  5-pin Plug
• Seals material
  NBR
• Material of adjusting screw
  Steel
• Material of plug housing
  Brass, nickel-plated
Type code
OVEM
Integrated function
Ejector pulse valve, electric Vacuum switch
Valve function
Closed
Displayable unit(s)
bar
Max. vacuum
93 %
Duty cycle
100%
Coil characteristics
24 V DC: low-current phase 0.3 W, high-current phase 2.55 W
Information on operating and pilot media
Operation with oil lubrication not possible
Temperature of medium
0 °C ... 50 °C
Certification
RCM compliance mark c UL us - Listed (OL)
Ambient temperature
0 °C ... 50 °C
Reproducibility, switching value FS
0.6 %
Pneumatic connection 3
Pneumatic muffler integrated
Note on materials
Contains paint-wetting impairment substances RoHS-compliant
Material of filter housing
PA-reinforced
Muffler material
Wrought aluminum alloy PU foam
Material of pin contacts
Brass, gold-plated
Width dimension
20 mm
Ejector characteristics
High vacuum Standard
Manual override
Non-detenting Additionally via operating buttons
Reverse polarity protection
for all electrical connections
Display range
-0.999 bar ... 0 bar
Setting range threshold value
-0.999 bar ... 0 bar
Operating pressure
2 bar ... 8 bar
Max. suction rate with respect to atmosphere
50.5 l/min
Inductive protective circuit
Adapted to MZ, MY and ME coils
Voltage drop
≤ 1.5 V
Surge resistance
0.8 kV
CE marking (see declaration of conformity)
As per EU EMC directive
Noise level at nominal operating pressure
77 dB(A)
Protection class
III
Accuracy in ± % FS
3 %FS
Type of mounting
With through-hole With accessories
Female nozzle material
POM
Inspection window material
PA
Mounting position
Any
Short-circuit protection
yes
Measuring principle
Piezoresistive
Switching input to standard
IEC 61131-2
Setting options
Via display and pushbuttons
Operating pressure for max. vacuum
3.6 bar
Nominal operating pressure
6 bar
Insulation voltage
50 V
Idle current
< 70 mA
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Degree of protection
IP65
Pressure measuring range
-1 bar ... 0 bar
Pneumatic connection 1
G1/4
Compressed air filter material
Fabric Sintered steel
Material of keypad
TPE-U
Switching element function
N/C contact N/O contact
Symbol
00992094
Setting range hysteresis
-0.9 bar ... 0 bar
DC operating voltage range
20.4 V ... 27.6 V
Residual current
0.1 mA
Overload protection
Available
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Product weight
385 g
Input switching logic
NPN (negative switching)
Vacuum connection
G1/4
Housing material
Die-cast aluminum PA-reinforced
Material of screws
Steel
Material of pins
Steel
Material of pneumatic fitting
Wrought aluminum alloy, anodized
