548095 Festo Pneumatic Actuators
Part#:548095
Alt. Part#:DHTG-220-8-A
Manufacturer:Festo
Category:Pneumatic Actuators
Product Lifecycle:Active
Product description
rotary indexing table DHTG-220-8-A For position sensing. Size: 220, Parallelity poppet valve: <: 0,04 mm, Axial ecc poppet valve: <: 0,02 mm, Concentricity poppet valve: <: 0,02 mm, Repetition accuracy of the swivel angle: <: 0,03 deg
Product Details
- Axial eccentricity of plate ≤ 0.02 mm
- Position sensing For inductive proximity sensors
- Ambient temperature 5 °C ... 60 °C
- Plate concentricity ≤ 0.02 mm
- Mode of operation Double-acting
- Operating pressure 4 bar ... 8 bar
- Max. pull-out torque static 500 Nm
- Spacing 8
- Stops material Steel, galvanized
- Size 220
- Repetition accuracy of swivel angle ≤ 0.03 deg
- Design Gear coupling Positively driven motion sequence
- Parallelism of plate ≤ 0.04 mm
- Type code DHTG
- Mounting position Any
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Max. axial force static 5000 N
- Cushioning Pneumatic shock absorber, hard characteristic curve, adjustable
- Symbol 00992251
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Max. radial force static 8000 N
- Type of mounting Via through-hole and centering sleeve
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Noise level ≤ 70 dB(A)
- Product weight 24000 g
- Max. tangential torque static 500 Nm
- Pneumatic connection Internal thread G1/8
- Seals material NBR TPE-U(PU)
- Theoretical torque at 6 bar 58.9 Nm
- Plate material Steel, galvanized
- Cover material Wrought aluminum alloy
- Note on materials Free of copper and PTFE RoHS-compliant
- Housing material Wrought aluminum alloy
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
