551376 Festo Proximity Sensors

Product Details

• Electrical connection 1, connection technology
  M8x1 A-coded as per EN 61076-2-104
• Conforms to standard
  EN 60947-5-2
• Type code
  SMT
• Electrical connection 1, connection type
  Cable with plug
• Symbol
  00991153
• Electrical connection 1, type of mounting
  Screw-type lock
• Repetition accuracy
  0.2 mm
• Design
  for round slot
• Switching element function
  N/O contact
• Max. switching frequency
  150 Hz
• Overload protection
  Available
• Reverse polarity protection
  for all electrical connections
• Product weight
  6.7 g
• KC characters
  KC EMC
• Note on materials
  Free of copper and PTFE Halogen-free
• Measured variable
  Position
• On time
  ≤ 1.3 ms
• Max. switching capacity DC
  2.8 W
• DC operating voltage range
  5 V ... 30 V
• Cable characteristic
  Suitability for energy chains/robot applications
Max. tightening torque
0.4 Nm
Electrical connection for input 1, connection pattern
00991155
Electrical connection 1, number of pins/wires
3
Special features
Oil-resistant
CE marking (see declaration of conformity)
As per EU EMC directive As per EU RoHS directive
Switch-off time
≤ 1.4 ms
Max. switching capacity DC in mounting kits
1.5 W
Short-circuit protection
yes
Material of cable sheath
TPE-U(PUR)
Mounting position
Any
Ambient temperature with flexible cable installation
-20 °C ... 70 °C
Certification
RCM compliance mark
Ambient temperature
-40 °C ... 70 °C
Switching output
PNP
Max. output current in mounting kits
50 mA
Rated operating voltage DC
24 V
Cable length
0.3 m
Housing material
PA-reinforced High-alloy stainless steel
Degree of protection
IP65 IP68
Measuring principle
Magneto-resistive
Max. output current
100 mA
Voltage drop
≤ 1.7 V
Connection outlet orientation
Transverse
Connector cable test conditions
Flexural strength: as per Festo standard Torsional resistance: > 300 000 cycles, ±270°/0.1 m
Type of mounting
Screwed tightly Can be inserted in slot from above
Switching status indication
LED yellow
