554041 Festo Proportional Valves

Product Details

• Nominal width pressurization
  6 mm
• Actuation type
  Electrical
• Symbol
  00995303
• Valve function
  3-way proportional pressure control valve
• Inlet pressure 1
  0 bar ... 8 bar
• Duty cycle
  100%
• Analog input signal range
  4 - 20 mA
• Degree of protection
  IP65
• Electrical connection
  8-pin Plug
• Pneumatic connection 3
  G1/8
• Type code
  VPPM
• Mounting position
  Any
• Reset method
  Mechanical spring
• Max. pressure hysteresis
  0.03 bar
• Residual ripple
  10 %
• Temperature of medium
  10 °C ... 50 °C
• Product weight
  400 g
• Type of mounting
  Optionally: With accessories
• Housing material
  Wrought aluminum alloy Anodized
• Design
  Pilot-controlled diaphragm regulator
Reverse polarity protection
for all electrical connections
Display type
LED
Max. electrical power consumption
7 W
DC operating voltage range
21.6 V ... 26.4 V
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
Information on operating and pilot media
Operation with oil lubrication not possible
CE marking (see declaration of conformity)
As per EU EMC directive
Linearity error FS
1 %
Note on materials
RoHS-compliant
KC characters
KC EMC
Short-circuit protection
For all electrical connections
Standard nominal flow rate
900 l/min
Analog output signal range
4 - 20 mA
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Certification
RCM compliance mark c UL us - Listed (OL)
Repetition accuracy FS
0.5 %
Pneumatic connection 2
G1/8
Exhaust nominal width
4.5 mm
Sealing principle
Soft
Safety instructions
VPPM safety position: if the supply cable breaks, the outlet pressure is maintained in uncontrolled form.
Type of control
Pilot-controlled
Pressure regulation range
0.06 bar ... 6 bar
Max. current consumption
300 mA
Switching output
PNP
Ambient temperature
0 °C ... 60 °C
Temperature coefficient
0.04 %/K
Pneumatic connection 1
G1/8
