558338 Festo Proportional Valves

558338 on Powermatic Associates
Festo

Part#:558338

Alt. Part#:VPPM-6L-L-1-G18-0L6H-A4P-C1

Manufacturer:Festo

Category:Proportional Valves

Product Lifecycle:Active

Product description

proportional pressure regulator VPPM-6L-L-1-G18-0L6H-A4P-C1 Nominal diameter, pressurisation: 6 mm, Nominal diameter, exhaust: 4,5 mm, Type of actuation: electrical, Sealing principle: soft, Assembly position: Any

Product Details

  • Nominal width pressurization
    6 mm
  • Sealing principle
    Soft
  • Symbol
    00995303
  • Type of control
    Pilot-controlled
  • Max. current consumption
    300 mA
  • Switching output
    PNP
  • Information on operating and pilot media
    Operation with oil lubrication not possible
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
  • Temperature coefficient
    0.04 %/K
  • Pneumatic connection 1
    G1/8
  • Note on materials
    RoHS-compliant
  • KC characters
    KC EMC
  • Type code
    VPPM
  • Mounting position
    Any
  • Reverse polarity protection
    for all electrical connections
  • Inlet pressure 1
    0 bar ... 8 bar
  • Duty cycle
    100%
  • Residual ripple
    10 %
  • Certification
    RCM compliance mark c UL us - Listed (OL)
  • Type of mounting
    Optionally: With accessories
  • Exhaust nominal width
    4.5 mm
  • Safety instructions
    VPPM safety position: if the supply cable breaks, the outlet pressure is maintained in uncontrolled form.
  • Valve function
    3-way proportional pressure control valve
  • Standard nominal flow rate
    900 l/min
  • Analog output signal range
    4 - 20 mA
  • CE marking (see declaration of conformity)
    As per EU EMC directive
  • Degree of protection
    IP65
  • Repetition accuracy FS
    0.5 %
  • Pneumatic connection 2
    G1/8
  • Short-circuit protection
    For all electrical connections
  • Design
    Pilot-controlled diaphragm regulator
  • Display type
    Back-lit LCD
  • Pressure regulation range
    0.06 bar ... 6 bar
  • DC operating voltage range
    21.6 V ... 26.4 V
  • Analog input signal range
    4 - 20 mA
  • Temperature of medium
    10 °C ... 50 °C
  • Product weight
    400 g
  • Linearity error FS
    2 %
  • Housing material
    Wrought aluminum alloy Anodized
  • Actuation type
    Electrical
  • Reset method
    Mechanical spring
  • Max. pressure hysteresis
    0.03 bar
  • Max. electrical power consumption
    7 W
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Ambient temperature
    0 °C ... 50 °C
  • Electrical connection
    8-pin Plug
  • Pneumatic connection 3
    G1/8

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
