558346 Festo Proportional Valves

Product Details

• KC characters
  KC EMC
• Mounting position
  Any
• Symbol
  00995303
• Display type
  Back-lit LCD
• Standard nominal flow rate
  900 l/min
• Information on operating and pilot media
  Operation with oil lubrication not possible
• Temperature of medium
  10 °C ... 50 °C
• Linearity error FS
  2 %
• Type of mounting
  Optionally: With accessories
• Housing material
  Wrought aluminum alloy Anodized
• Exhaust nominal width
  4.5 mm
• Sealing principle
  Soft
• Safety instructions
  VPPM safety position: if the supply cable breaks, the outlet pressure is maintained in uncontrolled form.
• Type of control
  Pilot-controlled
• Nominal width pressurization
  6 mm
• Actuation type
  Electrical
• Short-circuit protection
  For all electrical connections
• Reset method
  Mechanical spring
• Pressure regulation range
  0.06 bar ... 6 bar
• Max. electrical power consumption
  7 W
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Temperature coefficient
0.04 %/K
Pneumatic connection 1
G1/8
Pneumatic connection 3
G1/8
Type code
VPPM
Design
Pilot-controlled diaphragm regulator
Valve function
3-way proportional pressure control valve
DC operating voltage range
21.6 V ... 26.4 V
Residual ripple
10 %
CE marking (see declaration of conformity)
As per EU EMC directive
Degree of protection
IP65
Certification
RCM compliance mark c UL us - Listed (OL)
Pneumatic connection 2
G1/8
Reverse polarity protection
for all electrical connections
Inlet pressure 1
0 bar ... 8 bar
Max. current consumption
300 mA
Switching output
NPN
Analog input signal range
0 - 10 V
Ambient temperature
0 °C ... 50 °C
Electrical connection
8-pin Plug
Max. pressure hysteresis
0.03 bar
Duty cycle
100%
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
Analog output signal range
0 - 10 V
Product weight
400 g
Repetition accuracy FS
0.5 %
Note on materials
RoHS-compliant
