564638 Festo Pneumatic Fittings
Part#:564638
Alt. Part#:QBF-1/8-1/4-U
Manufacturer:Festo
Category:Pneumatic Fittings
Product Lifecycle:Active
Jun 17, 2025
Product description
push-in fitting QBF-1/8-1/4-U female thread with external hexagon. Size: Standard, Nominal size: 0,197 ", Type of seal on screw-in stud: coating, Assembly position: Any, Design structure: Push/pull principle
Product Details
- Type code QBF
- Temperature-dependent operating pressure -0.951 bar ... 9.997 bar
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Max. tightening torque 7 Nm
- Pneumatic connection 2 for pneumatic tubing outer diameter 1/4"
- Material of threaded seal PTFE
- Material of tube retaining claw High-alloy stainless steel
- Design Push-pull principle
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-]
- Pneumatic connection 1 Internal thread 1/8 NPT
- Releasing ring material POM
- Size Standard
- Type of seal on screwed trunnion Coating
- Operating pressure for entire temperature range -0.951 bar ... 9.997 bar
- Information on operating and pilot media Operation with oil lubrication possible
- Product weight 18.796 g
- Housing material Brass, nickel-plated
- Nominal width 5.004 mm
- Mounting position Any
- Ambient temperature 0 °C ... 60 °C
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Releasing ring color Gray
- Material of tubing seal NBR
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
