570362 Festo Pneumatic Tubing

570362 on Powermatic Associates
Festo

Part#:570362

Alt. Part#:PAN-MF-14X2-SW

Manufacturer:Festo

Category:Pneumatic Tubing

Product Lifecycle:Active

Product description

plastic tubing PAN-MF-14X2-SW Outside diameter: 14 mm, Bending radius relevant for flow rate: 75 mm, Inside diameter: 10 mm, Min. bending radius: 50 mm, Conforms to standard: DIN 73378-PA12-PHL

Product Details

  • Inside diameter
    10 mm
  • Ambient temperature
    -60 °C ... 100 °C
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Pneumatic tubing test conditions
    Suitability for energy chains: >5 million cycles as per FN 942021
  • Type code
    PAN-MF
  • Product weight by length
    0.077 kg/m
  • Pneumatic connection
    For plug connection outside diameter 14 mm
  • Tubing characteristics
    Suitable for energy chains in applications with high cycle rates
  • Min. bending radius
    50 mm
  • Temperature-dependent operating pressure
    -0.95 bar ... 22 bar
  • Shore hardness
    D 65 +/-3
  • Bending radius relevant for flow rate
    75 mm
  • Conforms to standard
    DIN 73378-PA12-PHL
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Mineral oil
  • Material of pneumatic tubing
    PA12-P
  • Outside diameter
    14 mm
  • Color
    Black

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
