574447 Festo Directional Control Valves
Part#:574447
Alt. Part#:VUVG-B18-T32U-MZT-F-1P3
Manufacturer:Festo
Category:Directional Control Valves
Product Lifecycle:Active
Product description
solenoid valve VUVG-B18-T32U-MZT-F-1P3 Valve function: 2x3/2 open, monostable, Type of actuation: electrical, Valve size: 18 mm, Standard nominal flow rate: 800 l/min, Operating pressure: -0,9 - 10 bar
Product Details
- Standard nominal flow rate 800 l/min
- Degree of protection IP40 With plug socket
- Exhaust air function With flow control option
- Type of control Pilot-controlled
- Pilot pressure MPa 0.2 MPa ... 0.8 MPa
- Design Piston gate valve
- Type code VUVG
- Manual override Detenting Covered
- On switching time 15 ms
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Product weight 164 g
- Valve function 2x3/2, open, monostable
- Pneumatic working port Flange
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Electrical connection Via electrical sub-base
- Housing material Wrought aluminum alloy
- Operating pressure -0.9 bar ... 10 bar
- Valve size 18 mm
- Operating voltage 24V DC
- Nominal width 5.7 mm
- Mounting position Any
- Pilot pressure 2 bar ... 8 bar
- Max. positive test pulse with 0 signal 700 µs
- Shock resistance Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
- Type of mounting On terminal strip
- Lap Overlap
- Actuation type Electrical
- Reset method Mechanical spring
- Certification RCM compliance mark c UL us - Recognized (OL)
- Sealing principle Soft
- Symbol 00992946
- Switching time off 22 ms
- Max. negative test pulse on 1 signal 900 µs
- Permissible voltage fluctuations +/- 10 %
- Restricted ambient and media temperature -5 - 50 °C Without holding power reduction
- Ambient temperature -5 °C ... 60 °C
- Note on materials RoHS-compliant
- Pilot air supply port External
- Duty cycle 100%
- Coil characteristics 24 V DC: 1.0 W 24 V DC: low-current phase 0.3 W, high-current phase 1.0 W
- Vibration resistance Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
- Temperature of medium -5 °C ... 60 °C
- Pilot medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Seals material HNBR NBR
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
