6257 Festo Pneumatic Fittings
Part#:6257
Alt. Part#:CK-1/4-PK-6-KU
Manufacturer:Festo
Category:Pneumatic Fittings
Product Lifecycle:Active
Product description
quick connector CK-1/4-PK-6-KU Male thread with sealing rim, polymer design. Nominal size: 5,3 mm, Type of seal on screw-in stud: Sealing edge, Assembly position: Any, Operating pressure complete temperature range: 0 - 10 bar, Maritime classification: see
Product Details
- Type of seal on screwed trunnion Sealing edge
- Mounting position Any
- Nominal width 5.3 mm
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Housing material POM
- Type code CK
- Operating pressure for entire temperature range 0 bar ... 10 bar
- Pneumatic connection 1 External thread G1/4
- Information on operating and pilot media Operation with oil lubrication possible
- Note on materials RoHS-compliant
- Maritime classification See certificate
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
- Pneumatic connection 2 for pneumatic tubing outside diameter 8 mm
- Ambient temperature -10 °C ... 60 °C
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
6257 Related Documents
Similar products from: Festo Pneumatic Fittings
Manufacturer warranty
6257 Festo
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 6257 with other Pneumatic Fittings products
Type of seal on screwed t...
Mounting position
Nominal width
Corrosion resistance clas...
Housing material
Type code
Operating pressure for en...
Pneumatic connection 1
Information on operating ...
Note on materials
Selected product
6257
Festo
quick connector CK-1/4-PK-6-KU Male thread with sealing rim, polymer design. Nominal size: 5,3 mm, T...
Type of seal on screwed trunnionSealing edge
Mounting positionAny
Nominal width5.3 mm
Corrosion resistance class (CRC)2 - Moderate corrosion stres...
Housing materialPOM
Type codeCK
Operating pressure for entire temperature range0 bar ... 10 bar
Pneumatic connection 1External thread G1/4
Information on operating and pilot mediaOperation with oil lubricati...
Note on materialsRoHS-compliant
2030
Festo
quick connector CK-1/4-PK-6 Male thread with sealing ring, metal version. Nominal size: 4,9 mm, Type...
Type of seal on screwed trunnionSealing ring
Mounting positionAny
Nominal width4.9 mm
Corrosion resistance class (CRC)2 - Moderate corrosion stres...
Housing material-
Type codeCK
Operating pressure for entire temperature range-
Pneumatic connection 1External thread G1/4
Information on operating and pilot mediaOperation with oil lubricati...
Note on materials-
2029
Festo
quick connector CK-1/4-PK-4 Male thread with sealing ring, metal version. Nominal size: 2,9 mm, Type...
Type of seal on screwed trunnionSealing ring
Mounting positionAny
Nominal width2.9 mm
Corrosion resistance class (CRC)2 - Moderate corrosion stres...
Housing material-
Type codeCK
Operating pressure for entire temperature range-
Pneumatic connection 1External thread G1/4
Information on operating and pilot mediaOperation with oil lubricati...
Note on materials-
About the manufacturer
Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to e...
About the Product Category
Air fittings, also referred to as pneumatic fittings or connectors, are crucial components of pneumatic systems. They ensure safe and airtight connections between various pneumatic elements like air hoses, tubes, valves, and cylinders.
