Powermatic Associates Logo

AB6635-D HMS Networks Industrial Automation Components

AB6635-D on Powermatic Associates
HMS Networks

Part#:AB6635-D

Manufacturer:HMS Networks

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Anybus CompactCom 40 Module PROFINET-IRT - Transparent Ethernet

Product Details

  • Content of Delivery
    CompactCom M40 module
  • Dual Usage (ERP)
    No
  • Isolation
    Galvanic Isolation
  • Operating Temperature °C Max
    70 °C
  • Operating Temperature °C Min
    -40 °C
  • HS Code
    8517620000
  • Net Width (ERP) (mm)
    50 mm
  • Application Interface
    8/16-bit parallel (30 ns access) High speed SPI, baudrate configurable up to 20 MHz I/O (shift register interface, cyclical update time 82 μs) UART (for backwards compatibility with 30-series, max 625kbps)
  • LED Indicators
    Integrated on front. Indicates Module Status, Network Status and Link/Activity.
  • Export Control Classification Number (ECCN) (ERP)
    EAR99
  • Current Consumption Class (CompactCom series)
    B
  • UL File Number
    E214107
  • Input Voltage (V)
    3.3 VDC, +/- 0.15 VDC
  • Storage Temperature °C Max
    85 °C
  • Net Depth (ERP) (mm)
    52 mm
  • Warranty (years)
    1 year
  • Mounting
    PCB mounting via a customized CompactFlash connector
  • Storage Temperature °C Min
    -40 °C
  • Form Factor
    Module
  • Net Weight (ERP) (g)
    28 g
  • Contains Battery
    No
  • Net Height (ERP) (mm)
    22 mm
  • Connectors / Input / Output
    2x RJ45
  • Country of Origin
    Sweden

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
