52110024 Lapp Electronic Components

Name: 52110024
Brand: Lapp

Part#:52110024

Manufacturer:Lapp

Category:Electronic Components

Product Lifecycle:Active

Product description

52110024 - LAPP SKINTOP® MS-M ATEX BRUSH Strain Relief Cable Gland - M32 x 1.5

Product Details

SERIES
SKINTOP® MS-M ATEX BRUSH
BUSHING
Special Elastomer
COLOR
Metallic
MANUFACTURER PART NUMBER
52110024
THREAD TYPE
Metric
STATIC TEMPERATURE RATING
-22°F to +194°F-30°C to +90°C
ADDITIONAL STANDARDS
ATEX
BODY MATERIAL
Nickel-plated brass
STANDARDS/APPROVALS
CE Approved
CLAMPING RANGE (MM)
11 - 21
CLAMPING RANGE (IN)
0.433 - 0.827
WRENCHING FLATS (IN)
1.418
DYNAMIC TEMPERATURE RATING
-22°F to +194°F-30°C to +90°C
THREAD LENGTH (IN)
0.355
IP RATING
IP68
THREAD SIZE
32
THREAD LENGTH (MM)
9.017
LOCKNUT
Not Included

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
