Powermatic Associates Logo

DT1-420-24U-U-FL NK Technologies Current Transducers

DT1-420-24U-U-FL on Powermatic Associates
NK Technologies

Part#:DT1-420-24U-U-FL

Manufacturer:NK Technologies

Category:Current Transducers

Product Lifecycle:Active

Product description

DT1-420-24U-U-FL NK Technologies - DT1-420-24U-U-FL, DC Current Transducers, Unipolar Output, Solid-Core

Product Details

  • Certifications
    CE, UL/cUL
  • Output Signal
    4-20 milliamps
  • Shipping Weight
    0.4 pounds
  • Flammability Class
    UL 94V-0
  • Isolation Voltage
    1270 volts, 5 kilovolts
  • Power Consumption
    2 volt-amperes
  • Case Style
    Foot Mount, Solid Core
  • Accuracy
    1 percent
  • Sensor Type
    DC Current Transducer
  • Range
    50-100 amperes

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of DT1-420-24U-U-FL on Powermatic Associates is $220.00. Order now.

About the product

The DT1-420-24U-U-FL, 4-Wire DC Current Transducer combines a Hall effect sensor and signal conditioner into a single package for use in DC current applications. The DT1-420-24U-U-FL DC Current Transducer features a unipolar design whereby current flows in only one direction through the sensor. Three user selectable ranges consisting of 0-50 amps, 0-75 amps and 0-100 amps. This transducer produces an industry standard 4-20ma analog output signal. Sold in a solid-core case. Requires a 24 VDC or VAC power supply.

DT1-420-24U-U-FL Related Documents

169dfee21bf643dcea891847f1e8a6aaf4352a5e.pdf

Manufacturer warranty

DT1-420-24U-U-FL NK Technologies

$220.00

Your price can be lower.
Log in or Create account to check your discount

Select Qty:

$220.00

$220.00 each

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

About the manufacturer

NK Technologies

Powermatic Associates is an authorized NK Technologies distributor, proudly offering a comprehensive selection of innovative industrial products tailored to meet the diverse needs of our customers. NK Technologies is renowned in the industry for its expertise in designing and manufacturing high-quality current sensing devices and motor protection solutions. Their extensive product line includes cu...
