7202A5TRDULP4 NSK Mechanical Components

Name: 7202A5TRDULP4
Brand: NSK

Part#:7202A5TRDULP4

Manufacturer:NSK

Category:Mechanical Components

Product Lifecycle:Active

Product description

Precision Ball Bearing; 15MM Bore; 35MM Outside Diameter; 22MM Width; Open Enclosure; ABEC 7 | ISO P4 Precision; Steel Ball Material; 2 (1 Pair) Bearing; 25 Degree Contact Angle; Phenolic Cage Material

Product Details

Brand
NSK
Cage Material
Phenolic
Contact Angle
25 Degree
Bore
0.591 Inch | 15 Millimeter
Number of Bearings
2 (1 Pair)
Enclosure
Open
Raceway Style
1 Rib Outer Ring
Outside Diameter
1.378 Inch | 35 Millimeter
Mounting Arrangement
Duplex-Universal
Weight / Kilogram
0.09
Minimum Buy Quantity
N/A
Inch - Metric
Metric
CATEGORY
Precision Ball Bearings
Other Features
Single Row | Angular Contact | Super Precision
Precision Class
ABEC 7 | ISO P4
Flush Ground
Yes
Material - Ball
Steel
Rolling Element
Ball Bearing
Preload
Light
Width
0.866 Inch | 22 Millimeter

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

7202A5TRDULP4 NSK

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

Compare 7202A5TRDULP4 with other Mechanical Components products

Brand

Cage Material

Contact Angle

Bore

Number of Bearings

Enclosure

Raceway Style

Outside Diameter

Mounting Arrangement

Weight / Kilogram

Selected product

Backordered

7202A5TRDULP4

NSK

Precision Ball Bearing; 15MM Bore; 35MM Outside Diameter; 22MM Width; Open Enclosure; ABEC 7 | ISO P...

BrandNSK

Cage MaterialPhenolic

Contact Angle25 Degree

Bore0.591 Inch | 15 Millimeter

Number of Bearings2 (1 Pair)

EnclosureOpen

Raceway Style1 Rib Outer Ring

Outside Diameter1.378 Inch | 35 Millimeter

Mounting ArrangementDuplex-Universal

Weight / Kilogram0.09

55 in stock
