UCP210D1 NSK Mechanical Components

UCP210D1 on Powermatic Associates

NSK

Part#:UCP210D1

Manufacturer:NSK

Category:Mechanical Components

Product Lifecycle:Active

Product description

Pillow Block Bearing; 2 Bolt Pillow Block; 50MM Bore; 57.2MM Base to Center Height; Set Screw Mount; Ball Bearing; Relubricatable; Cast Iron; Non-Expansion

Product Details

Weight / Kilogram
5.73
Seals
Single Lip Contact
Bore
1.969 Inch | 50 Millimeter
Brand
NSK
Housing Configuration
1 Piece Solid
Weight / LBS
5.95248
Mounting Method
Set Screw
Inch - Metric
Metric
Rolling Element
Ball Bearing
Base to Center Height
2.25 Inch | 57.2 Millimeter
CATEGORY
Pillow Block Bearings
Expansion / Non-expansion
Non-Expansion
Housing Style
2 Bolt Pillow Block
Relubricatable
Yes
Nominal Bolt Center to Center
6.3 Inch | 160 Millimeter
Mounting Bolts
16 Millimeter
Actual Bolt Center to Center
6.3 Inch | 159Millimeter
Number of Mounting Holes
2
Other Features
Single Row
Length Thru Bore
2.031 Inch | 51.6 Millimeter

Housing Material

Cast Iron

Minimum Buy Quantity

N/A

Insert Part Number

UC210D1

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty
