1407272 Phoenix Contact Electrical Wires & Cables

Product Details

• Rated current at 40°C
  2 A
• Status display
  No
• Degree of pollution
  3
• Contact material
  CuSn
• Contact surface material
  Ni/Au
• Ambient temperature (operation)
  -40 °C ... 105 °C (cable, fixed installation)
• Protective circuit/component
  unwired
• Torque
  0.4 Nm (M12 connector)
• Conductor cross section
  8x 0.25 mm²
• Conductor structure signal line
  32x 0.10 mm
• External cable diameter D
  6.8 mm ±0.2 mm
• Minimum bending radius, flexible installation
  10 x D
• ECLASS 4.1
  27060300
• Rated voltage
  30 V AC
• Number of positions
  8
• Insertion/withdrawal cycles
  ≥ 100
• Material of grip body
  PP
• Cable abbreviation
  Li2X2X
• Cable type (abbreviation)
  28X
• Length of twist, overall twist
  67 mm
Outer sheath thickness
approx. 1.3 mm
Minimum bending radius, drag chain applications
10 x D
Special properties
Irradiated
Length of cable
5 m
Standards/regulations
M12 connector IEC 61076-2-101
Flammability rating according to UL 94
V0
Standards/specifications
M12 connector IEC 61076-2-101
Thickness, insulation
approx. 0.25 mm (Core insulation)
Minimum bending radius, fixed installation
5 x D
Number of bending cycles
2000000
Traversing rate
3 m/s
Material conductor insulation
PE-X
Degree of protection
IP65
Insulation resistance
≥ 100 MΩ*km (at 20 °C)
Coding
A - standard
Contact carrier material
PP
Material, knurls
Stainless steel
Cable type
PE-X black
Core diameter including insulation
1.17 mm ±0.02 mm
Overall twist
8 wires around filler to the core
Traversing path
10 m
Cable weight
65 kg/km
Conductor material
Bare Cu litz wires
Resistance to oil
According to DIN EN 60811-2-1, 168 h at 100°C
ECLASS 10.0.1
27060311
ECLASS 5.0
27061800
ECLASS 9.0
27060311
UNSPSC 12.01
31251501
UNSPSC 13.2
31251501
Test voltage, cable
≥ 3000 V AC (Spark test)
ECLASS 4.0
27060300
ECLASS 6.0
27279200
External sheath, color
black-gray RAL 7021
Acceleration
10 m/s²
Material, filler
PP yarn
ETIM 6.0
EC001855
UNSPSC 21.0
31251501
UNSPSC 7.0901
31251501
Wire colors
white, brown, green, yellow, gray, pink, blue, red
UNSPSC 6.01
31251501
AWG signal line
24
Flame resistance
According to DIN EN 60332-1-2
Outer sheath, material
PE-X
REACh SVHC
Lead 7439-92-1
Nominal voltage, cable
≤ 300 V AC
Halogen-free
in accordance with DIN VDE 0472 part 815
ECLASS 11.0
27060311
ECLASS 5.1
27061800
ETIM 4.0
EC001855
ETIM 7.0
EC001855
China RoHS
Environmentally Friendly Use Period = 50 years
ECLASS 7.0
27279218
ETIM 3.0
EC001855
Conductor resistance
≤ 78 Ω/km (at 20 °C)
UNSPSC 19.0
31251501
UNSPSC 11
31251501
UNSPSC 20.0
31251501
Other resistance
Resistance to fuels according to IEC 60811, 168 h at 70°C
