305FX-SC Red Lion Industrial Automation Components

305FX-SC on Powermatic Associates
Red Lion

Part#:305FX-SC

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion 305FX-SC is an industrial Ethernet switch designed for automation networks. It operates with a supply voltage range of 10-30Vdc, including redundant power inputs to enhance system reliability. This switch features four RJ45 ports supporting 10/100BaseTX and one fiber optic SC connector for multi-mode fiber with a 2km rated optical length, suitable for 100BaseFX speed. The device is built to withstand ambient air storage temperatures ranging from -40 to +70 degrees Celsius. Encased in a metallic body for durability, it is designed for DIN rail mounting, aligning with IP20 rated voltage standards for electrical safety. The 305FX-SC is part of the N-Tron 300 series, identified by its 5-port configuration, and is classified under the UNSPSC code specific to Ethernet switches.

Product Details

  • Main function
    Ethernet Switch
  • Mounting mode
    DIN rail
  • Compliant with standard(s)
    CE IEEE 802.3 EN 55011 EN 61000-6-2 EN 61000-6-4 RoHS compliant UL Class 1 Division 2 Hazardous locations
  • Communication protocol
    Ethernet
  • Equivalent to
    305FXSC
  • Functions
    Industrial Ethernet switch
  • Order code / Manufacturer SKU
    305FX-SC
  • Ambient air temperature for operation
    -40...+70 °C
  • Material
    Metallic case
  • Primary brand
    Red Lion
  • Sub-range name
    N-Tron 300 series
  • Benefits
    Compact Size / Small Footprint High Reliability/Availability Extended environmental specifications Ruggedized DIN rail enclosure High Performance High MTBF >2M Hours (measured) Plug-and-Play operation Four Auto Sensing 10/100BaseTX RJ-45 Ports Auto Sensin
  • Connection capacity
    5-ports
  • Degree of protection
    IP20
  • Secondary brand
    N-Tron
  • Product series / family name
    Ethernet switches
  • Supply voltage (DC)
    10-30Vdc (12Vdc / 24Vdc) (redundant pwr. inputs)
  • Connection type
    4 x RJ45 ports (10/100BaseTX) 1 x Fiber optic SC connector (multi-mode; 100BaseFX; 2km rated optical fiber)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
