PAXCDS20 Red Lion Industrial Automation Components

PAXCDS20 on Powermatic Associates
Red Lion

Part#:PAXCDS20

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion PAXCDS20, part of the PAX2 series I/O modules, is an I/O unit designed with a quad setpoint output card. It features 4 digital outputs, each operating at 24Vdc with an open collector source configuration.

Product Details

  • Digital outputs
    4 x digital outputs (rly. contacts)
  • Main function
    I/O unit
  • Compliant with standard(s)
    CE
  • Product series / family name
    Process indicators
  • Order code / Manufacturer SKU
    PAXCDS20
  • Functions
    Quad setpoint rly. output card
  • Primary brand
    Red Lion
  • Sub-range name
    PAX2 series I/O modules
  • Technical compatibility with
    for PAX2 series devices

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

PAXCDS20 Related Documents

Red Lion - PAX2A - Product Manual.pdfRed Lion - PAX2D - Product Manual.pdfRed Lion - PAX2 PID Controllers - Product Manual.pdfRed Lion - PAX2S - Installation Guide.pdfRed Lion - PAX2 FlexCard - Data Sheet.pdfRed Lion - PAX2 PID Controllers - Data Sheet.pdfRed Lion - PAX2 PID Controllers - Installation Guide.pdfRed Lion - PAX2A - Installation Guide.pdfRed Lion - PAX2D - Installation Guide.pdfRed Lion - PAX2S - Product Manual.pdfRed Lion - PAX2C - Installation Guide.pdf
