PAXLIT00 Red Lion Industrial Automation Components

PAXLIT00 on Powermatic Associates
Red Lion

Part#:PAXLIT00

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion PAXLIT00 is a digital process timer and interval indicator from the PAX Lite series, designed to fit a 1/8 DIN (96x48mm) panel cutout with 14.2mm red digits for clear visibility. It operates on a wide supply voltage range of 50-250Vac, accommodating various AC power supplies including 48Vac, 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. This timer features a single digital input that can function as either sink or source, and it is housed in a casing that meets the IP65 and NEMA 4X standards for protection against dust and water ingress. The overall dimensions of the device are 96mm in width and 48mm in height, conforming to the 1/8 DIN horizontal standard.

Product Details

  • Display
    1 row x 3.5-digits red characters (14.2mm / 0.56" high) LED display
  • Supply voltage (AC)
    50-250Vac (48Vac / 100Vac / 110Vac / 120Vac / 200Vac / 208Vac / 220Vac / 230Vac / 240Vac)
  • Replaces
    APLIT405
  • Main function
    Ammeter (Digital)
  • Design
    1/8 DIN (96x48mm) 14.2mm red digits
  • Dimensions
    1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")
  • Primary brand
    Red Lion
  • Functions
    Current digital ammeter
  • Degree of protection
    IP65 NEMA 4X
  • Product series / family name
    Process indicators
  • Analog inputs
    1 x analog input (0-5A AC/DC; 16-bits conversion)
  • Order code / Manufacturer SKU
    PAXLIT00
  • Sub-range name
    PAX Lite series
  • Compliant with standard(s)
    CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

PAXLIT00 Related Documents

Red Lion - PAXLIT - Product Manual.pdf
