RBD48200 Red Lion Industrial Automation Components

RBD48200 on Powermatic Associates
Red Lion

Part#:RBD48200

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

T48/P48 output board - main control logic output - Red Lion (Process controllers T48 I/O modules series) - for T48 / P48 series devices

Product Details

  • Compliant with standard(s)
    CE
  • Main function
    I/O unit
  • Functions
    T48/P48 output board
  • Order code / Manufacturer SKU
    RBD48200
  • Product series / family name
    Process controllers
  • Technical compatibility with
    for T48 / P48 series devices
  • Primary brand
    Red Lion
  • Sub-range name
    T48 I/O modules
  • Design
    main control logic output

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

RBD48200 Related Documents

Red Lion - T48 PID controllers - Datasheet.pdfRed Lion - T48 P48 TLA Output Board - Product Manual.pdfRed Lion - T48-P48 - Instruction Manual.pdf
