Part#:8501CDO15V53

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - 8501CDO15V53

Product Details

  • Horsepower Rating
    2.0 hp
  • Short Name
    Type C
  • Coil Burden
    2 W
  • Product Type
    Power relay
  • [In] Rated Line Current
    30 A
  • Phase
    1 phase
  • Mounting
    Panel mounting
  • [Uc] Control Circuit Voltage
    24 V DC
  • Terminal Tightening Torque
    11…15 lbf.in (1.24…1.69 N.m)
  • Product Range
    Power Relay 8501C
  • Class Number
    8501
  • Device Application
    Suited for controlling small single phase motors and other light loads
  • Maximum Switching Voltage
    600 V AC
  • Switch Function
    SPDT
  • Wire Range
    AWG 10 copper
  • Contact Composition
    1 NO/1 NC
  • Terminal Connects
    Screw clamp terminal

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
