BDL26000S12 Schneider Electric Industrial Automation Components

Product Details

• Short-Circuit Withstand
  25 kA 208Y/120 V UL 489 25 kA 240 V UL 489 18 kA 480Y/277 V UL 489 18 kA 480 V UL 489 14 kA 600 V UL 489
• AWG Gauge
  AWG 6...AWG 2/0 fine stranded aluminium/copper AWG 14...AWG 3/0 rigid or stranded aluminium/copper
• Electrical Connection
  Everlink lug line Everlink lug load
• Number Of Slots
  1 auxiliary switch OF plug-in) 1 voltage release MN or MX plug-in)
• Mounting Mode
  Clip-on 35 x 15 mm symmetrical DIN rail) By screws plate)
• Tightening Torque
  44.25 lbf.in (5 N.m) 0.00…0.02 in² (2.5…10 mm²) 79.66 lbf.in (9 N.m) 0.02…0.15 in² (16…95 mm²)
• Width
  1.42 in (36 mm)
• Quantity Per Set
  Set of 1
• Depth
  3.50 in (89 mm)
• Height
  5.39 in (137 mm)
• 9 Mm Pitches
  6
• Color
  Grey (RAL 7016)
• Power Wire Stripping Length
  0.79 in (20 mm)
• Local Signalling
  for presence of auxiliary contacts flag (green)
• Connection Pitch
  1.06 in (27 mm)
• Contact Position Indicator
  Yes
• [Ue] Rated Operational Voltage
  600Y/347 V AC 50/60 Hz UL 489
• Electrical Durability
  10000 cycles IEC 947-1 Annex K ed 5.2 440 V In
• Mechanical Durability
  15000 cycles IEC 947-1 Annex K ed 5.2
• Magnetic Tripping Current
  1320 A
Magnetic Hold Current
880 A
Device Application
Distribution
Product Or Component Type
Automatic switch
Product Name
PowerPact B
Breaking Capacity Code
D
Control Type
Toggle
Number Of Poles
2P
Line Rated Current
125 A
Range
PowerPact
