Part#:EDB24030LH

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - EDB24030LH

Product Details

  • Net Weight
    3 lb(US) (1.36 kg)
  • Product Or Component Type
    Miniature circuit-breaker
  • Electrical Connection
    High ampere lugs aluminium
  • Trip Unit Rating
    875 A
  • Number Of Spaces
    2
  • Tightening Torque
    30.09 lbf.in (3.4 N.m) 0.00…0.02 in² (2.5…16 mm²) (AWG 14...AWG 6)
  • Number Of Poles
    2
  • Width
    1.96 in (49.78 mm)
  • Maximum Operating Voltage
    480Y/277 V AC
  • Mounting Mode
    Bolt-on
  • Breaking Capacity Code
    D
  • Local Signalling
    Trip indicator
  • Trip Unit Technology
    Thermal-magnetic
  • Line Rated Current
    30 A
  • Device Short Name
    EDB
  • Height
    5.66 in (143.76 mm)
  • Product Destination
    NF panelboard
  • Depth
    4.05 in (102.87 mm)
  • Range Of Product
    125 A Frame EDB-EGB-EJB
  • Module Type
    E-Frame
  • Holding Current
    270 A
  • Number Of Spaces Required
    2
  • Circuit Breaker Application
    HID rated HACR rated
  • AWG Gauge
    AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper
  • Protection Type
    Overload Short-circuit
  • Breaking Capacity
    18 kA 277 V AC 25 kA 240 V AC 18 kA 480Y/277 V AC 25 kA 120 V AC 25 kA 120/240 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EDB24030LH on Powermatic Associates is $643.00. Order now.
