Part#:H361

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Schneider Electric H361 is a switch-disconnector that falls under the Safety Switches (Heavy Duty) sub-range, specifically designed as a General Duty Single Throw Safety Switch (Fused). It features 3 poles and is rated for a current of 30 A. The dimensions of this part are a net height of 371 mm, a net width of 165 mm, and a net depth of 124 mm. It operates via a toggle mechanism. The H361 has a short circuit breaking rating of 10kA maximum with fuse types H or K and can reach up to 200kA maximum with fuse types R, J, or L. It is equipped with lug type terminals and is designed to handle a rated voltage (AC) of 600 V phase-to-phase.

Product Details

  • Device Application
    Heavy application
  • Phase
    3 phase
  • Duty Rating
    Heavy duty
  • Electrical Connection
    Lugs
  • Product
    Single Throw Safety Switch
  • Enclosure Rating
    NEMA 1 steel
  • Wiring Configuration
    3-wire (3P)
  • Net Weight
    9.02 lb(US) (4.09 kg)
  • Disconnect Type
    Fusible disconnect
  • Voltage Rating
    600 V AC/DC
  • Mounting Type
    Surface
  • Height
    14.6 in (370.84 mm)
  • Current Rating
    30 A
  • Factory Installed Neutral
    None
  • Number Of Poles
    3
  • Depth
    4.87 in (123.70 mm)
  • Width
    7.55 in (191.77 mm)
  • Fuse Type
    H or K R, J or L
  • Wire Size
    AWG 12...AWG 6 aluminium AWG 14...AWG 6 copper
  • Short Circuit Current Rating
    10 kA H or K 200 kA R, J or L
  • Tightening Torque
    45 lbf.in (5.08 N.m) 0.02 in² (13.3 mm²) (AWG 6) 40 lbf.in (4.52 N.m) 0.01 in² (8.367 mm²) (AWG 8) 35 lbf.in (3.95 N.m) 0.00…0.01 in² (2.06…5.261 mm²) (AWG 14...AWG 10)
  • Maximum Horse Power Rating
    5 hp 480 V at AC 50-60 Hz for 3 phase conforming to NEC 240.6 15 hp 480 V at AC 50-60 Hz for 3 phase conforming to NEC 430.52 7.5 hp 600 V at AC 50-60 Hz for 3 phase conforming to NEC 240.6 20 hp 600 V at AC 50-60 Hz for 3 phase conforming

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
