Part#:EX150T3HNLP

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - EX150T3HNLP

Product Details

  • Coil Material
    Aluminium
  • X/R Ratio
    2.24
  • Width
    40.08 in (1018 mm)
  • Device Application
    Low voltage electrical distribution
  • Transformer Type
    Energy efficient
  • Rated Operational Power In VA
    150 kVA
  • Basic IMP Level (BIL)
    10 kV
  • Net Weight
    1545.00 lb(US) (700.8 kg)
  • Type Of Cooling
    Natural convection
  • %IZ
    3.00 %
  • Device Short Name
    DOE 2016
  • Let Through Current
    13.7 kA
  • Height
    57.52 in (1461 mm)
  • Product Or Component Type
    Transformer
  • Primary Voltage
    480 V delta
  • %IX
    0.0278 %
  • Phase
    3 phase
  • Range Of Product
    Square D
  • DOE Efficiency
    99.03 % at 35 % load factor , 167 °F (75.0 °C)
  • Network Frequency
    60 Hz
  • Secondary Voltage
    208Y/120 V
  • Depth
    32.76 in (832 mm)
  • Transformer Losses
    328.0 no load (core loss) 1866.0 load loss (coil loss)
  • Temperature Rise
    150 °C 220 °C insulated
  • Sound Level
    49 dB 7 dB
  • Mounting Support
    Floor Floor, with 7400FMB
  • Number Of Tap-Offs
    2 2.5 % FCAN 4 2.5 % FCBN
  • Degree Of Protection
    UL type 1 UL type 2, with 7400DS25J UL type 3R, with 7400WS25J
  • Electrical Connection
    4 Hole Nema Pad primary 0.44 in (11.1 mm) 6 Hole Nema Pad secondary 0.44 in (11.1 mm) 8 Hole Nema Pad sec - XO 0.44 in (11.1 mm)
  • Transformer BTU/HR
    1294.579320352 16.6 % 1517.0605 25 % 2710.834 50 % 4700.4565 75 % 7485.928 100 %

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EX150T3HNLP on Powermatic Associates is $13,891.00. Order now.
