Part#:HJL36040

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HJL36040 is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HJL sub-range, featuring a PowerPact H-Frame 150 TMD 3P 40A 600Vac/250Vdc 25kA design. It is equipped with lugs on both load and line sides for connection, and it operates with three poles (3P). This MCCB offers thermal protection for overload scenarios and magnetic protection against short-circuits. It has a rated current of 40A, with a rated insulation voltage (Ui) of 750 V, and it can handle rated voltages of 600Vac 600Y/347Vac and 250Vdc. The unit is designed for individual mounting on a plate, with dimensions of 163 mm in height, 104 mm in width, and 86 mm in depth. It provides an IP40 degree of protection and features a manual toggle operating mode. Protection settings include over-current fixed at 40A, short-circuit hold current fixed at 400A, and short-circuit trip current fixed at 850A. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 40 AT, with a frame current rating of 150 AF. Its short circuit breaking rating varies with voltage, offering 100kA at 240Vac, 65kA at 480Vac and 480Y/277Vac, 25kA at 600Vac and 600Y/347Vac, and 20kA at 250Vdc, all in accordance with UL489 standards. The trip unit type is thermal-magnetic (fixed), and it does not include a display. The utilisation category is A.

Product Details

  • Magnetic Hold Current
    400 A
  • Depth
    4.36 in (110.74 mm)
  • Number Of Poles
    3P
  • Mounting Mode
    Unit mount
  • Height
    6.4 in (162.56 mm)
  • Product Or Component Type
    Circuit breaker
  • Width
    4.12 in (104.65 mm)
  • Line Rated Current
    40 A
  • Range Of Product
    PowerPact H
  • Magnetic Tripping Current
    850 A
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Breaking Capacity Code
    J
  • Continuous Current Rating
    80 %
  • Shipping Weight:
    4.20 lbs.
  • UPC:
    78590170655
  • Shipping Height:
    6.00 In.
  • Shipping Length:
    9.00 In.
  • Shipping Width:
    8.00 In.
  • Electrical Connection
    Lugs load Lugs line

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HJL36040 on Powermatic Associates is $1,949.00. Order now.
